INJECTION UNIT

A

B

C

Screw diameter

mm

45

50

55

Screw L/D ratio

L/D

22.2

20

18.2

Shotvolume(theoretical)

cm3

406

508

570

Injection weight(ps)

g

369

462

518

Injection rate

g/s

120

148

179

Plasticizing capacity

g/s

26.2

31.5

37

Injection pressure

Mpa

216

180

160.8

Screw speed

rpm

0-180

CLAMPING UNIT

Clamping force

kN

2180

Open stroke

mm

470

Spacebetweentiebars(w*h)

mm

520*520

Max.Mould height

mm

530

Min.Mould height

mm

200

Ejector stroke

mm

135

Ejector tonnage

kN

700

Ejector force

N

9

OTHERS

Max.Pump pressure

Mpa

16

Pump motor power

kW

18.5

Heating power

kW

11.65

Machine dimension(l*w*h)

Mpa

5.4*1.5*2

Machine weight

t

6.5

Oil tank capacity

L

340

Shot stroke

mm

330
