DESCRIPTION

Unit

Technical Parameters

Screw Diameter

mm

42

45

50

Injection Capacity

cm3

277

318

392

Injection Weight

g

252

289

357

Injection Rate

g/s

105

121

149

Plasticizing Capacity

g/s

17.5

19

23

Injection Pressure

Mpa

203

177

143

Screw Speed

Rpm

0-180

Clamp Tonnage

KN

1680

Moulding Board Movement

mm

430

Space Between Tie-bars(W*H)

mm

460*440

Max Mould Thickness

mm

500

Min Mould Thickness

mm

200

Ejector Distance

mm

152

Ejector Tonnage

KN

33

Max Pump Pressure

Mpa

16

Pump Motor Power

KW

15

Hester Power

KW

9.4

Machine Dimensions(L*W*H)

m*m*m

4.91*1.52*2

Machine Weight

T

5.5
